Pwen esansyèl
● Jiska 2.5 Gb/s done lyen
●DWDM EML lazè transmetè ak APD foto-detektè
●100 GHz ITU chanèl espacement ak kazye longèdonn entegre
● Jiska 80km sou 9/125µm SMF
●Hot-pluggable SFP anprint
●Duplex LC/UPC tip pluggable ptik entèfas
●Low pouvwa dissipation
●Metal boîtier, pou pi ba EMI
●RoHS konfòme ak plon-gratis
●Support Digital Diagnostic Siveyans koòdone
●Single +3.3V ekipman pou pouvwa
●Compliant ak SFF-8472
●Case opere tanperati
●Komèsyal: 0 ~ +70℃
●Extended: -10 ~ +80℃
●Endistriyèl: -40 ~ +85℃
Enfòmasyon sou lòd
Nimewo Pati | To Done (Gb/s) | Longèdonn (nm) | Distans transmisyon (km) | Tanperati (oC) (Ka opere) |
HTSF-1D2GCxxZC | 2.5 | 1528-1563nm | 80km SMF | 0 ~ 70 komèsyal |
HTSF-1D2GCxxZE | 2.5 | 80km SMF | -10 ~ 80 Pwolonje | |
HTSF-1D2GCxxZI | 2.5 | 80km SMF | -40 ~ 85 Endistriyèl |
Spesifikasyon
Paramèt | Senbòl | Min. | Tipik | Max | Inite | Nòt |
Transmetè | ||||||
Longèdonn optik | λC | λc -0.1 | λc +0.1 | nm | 1 | |
Sant espas longèdonn | 100 | GHz | ||||
Spectre Bandwidth (RMS) | σ | 1 | nm | |||
Side Mode Suppression rapò | SMSR | 30 | dB | |||
Mwayèn pouvwa optik | PAVG | 0 | 4 | dBm | 2 | |
Pwopòsyon disparisyon optik | ER | 8.2 | dB | |||
Transmetè OFF Sorti pouvwa | POff | -45 | dBm | |||
Mask je transmetè | Konfòme ak G.957 (klas 1 sekirite lazè) | |||||
Reseptè | ||||||
Longèdonn Sant | λC | 1270 | 1610 | nm | ||
Sansiblite reseptè (Mwayèn pouvwa) | Sen. | -28 | dBm | 3 | ||
Pouvwa Saturasyon Antre (Surcharge) | Psat | -9 | dBm | |||
LOS Afime | LOSA | -41 | dB | 4 | ||
LOS De-afime | PÈDI | -29 | dBm | 4 | ||
LOS isterèz | LOSH | 0.5 | 2 | 6 | dBm | |
