● Jiska 1.25 Gb/s done lyen
●1310nm FP lazè transmetè ak PIN foto-detektè
● Jiska 550m sou 50/125um MMF
●Hot-pluggable SFP anprint
●Duplex LC/UPC tip pluggable ptik entèfas
●Low pouvwa dissipation
●Metal boîtier, pou pi ba EMI
●RoHS konfòme ak plon-gratis
●Support Digital Diagnostic Siveyans koòdone
●Single +3.3V ekipman pou pouvwa
●Compliant ak SFF-8472
●Case opere tanperati
Komèsyal: 0 ~ +70oC
Pwolonje: -10 ~ +80oC
Endistriyèl: -40 ~ +85oC
Spesifikasyon
Paramèt | Senbòl | Min. | Tipik | Max | Inite | Nòt |
Transmetè | ||||||
CenterWavelength | λC | 1270 | 1310 | 1360 | nm | |
SpectrumBandwidth (RMS) | σ | 3.5 | nm | |||
Average OpticalPower | PAVG | -9 | -3 | dBm | 1 | |
Rapò disparisyon | ER | 9 | dB | |||
TransmitterOFFOutputPower | Poff | -45 | dBm | |||
TransmitterEyeMaskDefinition | Konfòme avèk 802.3z (class1lasersafety) | 2 | ||||
Reseptè | ||||||
CenterWavelength | λC | 1270 | 1610 | nm | ||
Sansiblite (Pousans Mwayèn) | Sen. | -19 | dBm | 3 | ||
InputSaturationPower (Surcharge) | Psat | -3 | dBm | |||
LOSAssert | LOSA | -35 | dBm | 4 | ||
LOSDe-afime | PÈDI | -20 | dBm | 4 | ||
LOSIsterèz | LOSH | 0.5 | dB |
Enfòmasyon sou Kòmann Nimewo Pati
Part Number | DataRate (Gb/s) | Longèdonn (nm) | Distans Transmisyon (m) | Tanperati (oC) (OperatingCase) |
HTSF-M1G31MC | 1.25 | 1310 | 550mMMF | 0 ~ 70komèsyal |
HTSF-M1G31ME | 1.25 | 1310 | 550mMMF | -10 ~ 80 Pwolonje |
HTSF-M1G31MI | 1.25 | 1310 | 550mMMF | -40 ~ 85Endistriyèl |
